LS-WS2201 Wireless solar camera

For solar cameras, there are low power wifi version, low power 4G version and CCTV conventional DC 12v input 4G version available now.
Using solar energy and battery to offer power to the cameras, they can work for a very long time. Also they can be continuously powered.
They’re environmentally friendly and energy-saving, and effectively solves the problem of the video surveillance solution of the places without power supply and network. They can reduce the trouble of laying power and network cables, and installation is simple and convenient.
They can be applied to house walls, yards, fish ponds, orchards, farms, mines, construction sites and all places where electricity and wiring are not convenient.

Weight 1.72 kg
Dimensions 77.0 × 60.6 × 44.4 cm
Power

Solar&Battery

Waterproof

IP66

Model: LS-WS2201

Main characteristics:

1. 1080p wifi solar powered PTZ camera
2. Pan&Tilt:Pan 320 degree&Tilt 90 degree
3. 8W solar panel,built-in 15600mAh 6 pcs 18650 batteries
4. Two-way voice intercom
5. Local video storage maximum 128G
6. WIFI 2.4GHz , IEEE 802.11 b/g/n, remote viewing/playback via APP (Mycam)
7. Automatic video recording and message push when human body motion wakes up
8. 4mm lens, 4 white light lamps + 2 infrared lamps, IR distance 15 meters

Application scenarios:

Ls-WS2201 low power solar camera, suitable for houses, yards, fish ponds, orchards, farms, mines, construction sites and all inconvenient power and wiring places.

Weight 1.72 kg
Dimensions 77.0 × 60.6 × 44.4 cm
Power

Solar&Battery

Waterproof

IP66

Specifications

Model: LS-WS2201
Motion: HMD(Human Motion Detection)
Chipset: Ingenic T21Z
Sensor:   1/2.7″  CMOS
Wifi module: 7682
Wifi Protocols: WIFI 2.4GHz, IEEE 802.11 b/g/n
Protocols: TCP/IP,HTTP,TCP,UDP,SMTP,DHCP,DNS,P2P
Pan&Tilt Pan:320º    Tilt:90º
Pixels: 2MP
Solution: 1920*1080
Lens: 4mm
Shoot-Distance: 0-15M
Shoot-Angle: 360º
Wake Time: 0.6 Seconds
Battery: 15600mAh
Solar Panel: 8W
Night-Led: White&IR Red Led
White Led: 1W  LED
IR Led: 1W  LED
TF Card: Maximore 64GB looping Video Recording
Motion Distance: 0-12M
Motion Angle: 120º
Temperature: -15℃ TO 60℃
Humidity: 0%-90%RH
Power: Solar&Battery
Standy Power Consumption: 0.08W
Working Power Consumption: DAY≤2W,NIGHT≤2.8W
Waterproof: IP66
Accessories: Camera*1、Solar Panel*1、Bracket*1、Screw Bag*1、Manual Book*1、Tools
Camera Size: 220mm*170mm*115mm
 Camera Weight 0.52kg
Solar Panel Size: 243mm*183mm*45mm
Solar Panel Weight: 0.87kg(Including 6PCS 18650 Battery)
Packing Size: 288mm*207mm*148mm
G.W/PCS: 1.72kg(Including 6PCS 18650 Battery)
Outer Box Size: L770mm*W606mm*H444mm
G.W/CTN: 29.5kg(Including Battery)
Quantiy/CTN: 16PCS/CTN

download

LS-WS2201 Specification

LS-WS2201 Operation manual
